Please contact us for more photos of HL6545MG07-A
| Part Number | HL6545MG07-A |
|---|---|
| Manufacturer | Oclaro |
| Quantity in stock | 583540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | VISIBLE LASER DIODE |
| Category | Optoelectronics |
| Family | Infrared |
| ROHS Compliant | Yes |
| MSL Level | HL6545MG07-A |
| Datasheet download |  HL6545MG07-A.pdf |
| Part Number | HL6545MG07-A |
|---|---|
| Screening Level | Commercial |
| Rad Hard | No |
| Lead Free | Yes |
| Family | HL6545MG |
| Photodiode Reverse Voltage | 2 V |
| Typical Single Supply Voltage | 2.5 V |
| Half Intensity Angle Parallel | 12 ° |
| Half Intensity Angle Perpendicular | 19 ° |
| Operating Temperature | -10 to 75 °C |
| Maximum Single Supply Voltage | 3.3 V |
| Laser Reverse Voltage | 2 V |
| Type | MQW-LD |
| Power Supply Type | Single |
| Maximum Operating Current | 210 mA |
| Mounting | Through Hole |
| Wavelength | 642 nm |
| Maximum Optical Output Power | 130 mW |
| Maximum Threshold Current | 75 mA |
| Package | 3CAN |
| Replacement Part Number | PART-HL6545MG07-A |
| Weight | Contact us |
| Country of Origin | - |
