| Part Number | HCPL-060L-500E |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 368240 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Optocoupler Logic-Out Open Collector DC-IN 1-CH 8-Pin SOIC T R |
| Category | Optoelectronics |
| Family | OptoCouplers |
| ROHS Compliant | Yes |
| MSL Level | HCPL-060L-500E |
| Datasheet download |  HCPL-060L-500E.pdf |
| Part Number | HCPL-060L-500E |
|---|---|
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Maximum Forward Voltage | 1.75 V |
| Maximum Reverse Voltage | 5 V |
| Input Type | DC |
| Supplier Package | SOIC |
| Product Dimensions | 5.08 x 3.94 x 3.18 mm |
| Maximum Baud Rate | MBd |
| MSL Level | 1 |
| Pin Count | 8 |
| Direction Type | Uni-Directional |
| Typical Fall Time | 0.02 us |
| Maximum Forward Current | 20 mA |
| Output Type | Open Collector |
| Maximum Propagation Delay Time | 90 ns |
| Logic Gate Type | NAND |
| Minimum Forward Voltage | 1.4 V |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Maximum Power Dissipation | 85 mW |
| Package | 8SOIC |
| Replacement Part Number | PART-HCPL-060L-500E |
| Weight | Contact us |
| Country of Origin | - |
