DS1685S-5+T&R Maxim Integrated

DS1685S-5+T&R Images

Please contact us for more photos of DS1685S-5+T&R

Part Number	DS1685S-5+T&R
Manufacturer	Maxim Integrated
Quantity in stock	614160 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Real Time Clock Multiplexed 242Byte 24-Pin SOIC W T R
Category	Logic & Timing IC
Family	Real Time Clock
ROHS Compliant	Yes
MSL Level	DS1685S-5+T&R
Datasheet download	DS1685S-5+T&R.pdf

Request Quotation for DS1685S-5+T&R

DS1685S-5+T&R Specifications

Part Number	DS1685S-5+T&R
Lead Finish	Matte Tin
Product Dimensions	15.6 x 7.6 x 2.35 mm
Pin Count	24
Supplier Package	SOIC W
Operating Supply Voltage	5 V
Screening Level	Commercial
Function	Clock/Calendar/Alarm
MSL Level	1
Mounting	Surface Mount
Bus Type	Multiplexed
Date Format	DW:DM:M:Y\|Binary
Operating Temperature	0 to 70 °C
Rad Hard	No
Max Processing Temp	260
Time Format	HH:MM:SS\|Binary
Package	24SOIC W
Replacement Part Number	PART-DS1685S-5+T&R
Weight	Contact us
Country of Origin	-
