MAX1230BCEG+T Maxim Integrated

MAX1230BCEG+T Images

Please contact us for more photos of MAX1230BCEG+T

Part Number MAX1230BCEG+T
Manufacturer Maxim Integrated
Quantity in stock 643600 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description ADC Single SAR 300ksps 12-bit Serial 24-Pin QSOP T R
Category Data Conversion IC
Family ADC
ROHS Compliant Yes
MSL Level MAX1230BCEG+T
Datasheet download MAX1230BCEG+T.pdf
Request Quotation for MAX1230BCEG+T

MAX1230BCEG+T Specifications

Part Number MAX1230BCEG+T
Number of ADCs 1
Differential Input Yes
Sampling Rate 300 ksps
Maximum Single Supply Voltage 5.25 V
Operating Temperature 0 to 70 °C
Integral Nonlinearity Error ±1 LSB
Product Dimensions 8.74 x 3.99 x 1.55 mm
Supplier Package QSOP
Rad Hard No
Polarity of Input Voltage Unipolar|Bipolar
Single-Ended Input Yes
Voltage Supply Source Single
Max Processing Temp 260|300
Full Scale Error ±4 LSB
Sample and Hold Yes
Pin Count 24
Minimum Single Supply Voltage 4.75 V
Number of Analog Inputs 16|8
Input Signal Type Single-Ended|Differential
Mounting Surface Mount
Input Type Voltage
Lead Finish Matte Tin
Differential Nonlinearity ±1 LSB
Input Voltage 4.096|±2.048 V
Signal to Noise Ratio 70 dB
Voltage Reference Internal|External
MSL Level 1
Typical Single Supply Voltage 5 V
Maximum Power Dissipation 762 mW
Digital Interface Type Serial (3-Wire, SPI, QSPI, Microwire)
Package 24QSOP
Replacement Part Number PART-MAX1230BCEG+T
Weight Contact us
Country of Origin -
