Please contact us for more photos of MAX1247BCEE+
| Part Number | MAX1247BCEE+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 183300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 133ksps 12-bit Serial 16-Pin QSOP |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | MAX1247BCEE+ |
| Datasheet download |  MAX1247BCEE+.pdf |
| Part Number | MAX1247BCEE+ |
|---|---|
| Typical Power Dissipation | 9 mW |
| Number of ADCs | 1 |
| Typical Single Supply Voltage | 3.3|5 V |
| Minimum Single Supply Voltage | 2.7 V |
| Pin Count | 16 |
| Input Signal Type | Single-Ended|Pseudo-Differential |
| Operating Temperature | 0 to 70 °C |
| Differential Input | Yes |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Integral Nonlinearity Error | ±1 LSB |
| Supplier Package | QSOP |
| Voltage Reference | External |
| Rad Hard | No |
| Maximum Single Supply Voltage | 5.25 V |
| Voltage Supply Source | Single |
| Single-Ended Input | Yes |
| Full Scale Error | ±4 LSB |
| No Missing Codes | 12 Bit |
| Digital Interface Type | Serial (4-Wire, SPI, QSPI, Microwire) |
| Max Processing Temp | 260|300 |
| Sample and Hold | Yes |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Product Dimensions | 4.98 x 3.99 x 1.55 mm |
| Input Voltage | 2.5|±1.25 V |
| Differential Nonlinearity | ±1 LSB |
| Screening Level | Commercial |
| Lead Finish | Matte Tin |
| Sampling Rate | 133 ksps |
| MSL Level | 1 |
| Number of Analog Inputs | 4|2 |
| Maximum Power Dissipation | 667 mW |
| Package | 16QSOP |
| Replacement Part Number | PART-MAX1247BCEE+ |
| Weight | Contact us |
| Country of Origin | - |
