Please contact us for more photos of MAX147BCAP+T
| Part Number | MAX147BCAP+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 617460 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 133ksps 12-bit Serial 20-Pin SSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | MAX147BCAP+T |
| Datasheet download |  MAX147BCAP+T.pdf |
| Part Number | MAX147BCAP+T |
|---|---|
| Lead Finish | Matte Tin |
| Full Scale Error | ±4 LSB |
| No Missing Codes | 12 Bit |
| Digital Interface Type | Serial (4-Wire, SPI, QSPI, Microwire) |
| Sample and Hold | Yes |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Differential Nonlinearity | ±1 LSB |
| Input Voltage | 2.5|±1.25 V |
| Maximum Power Dissipation | 640 mW |
| Screening Level | Commercial |
| Architecture | SAR |
| Product Dimensions | 7.33 x 5.38 x 1.78 mm |
| Sampling Rate | 133 ksps |
| Digital Supply Support | No |
| Number of Analog Inputs | 8|4 |
| MSL Level | 1 |
| Pin Count | 20 |
| Resolution | 12 Bit |
| Max Processing Temp | 260|300 |
| Voltage Supply Source | Single |
| Single-Ended Input | Yes |
| Number of ADCs | 1 |
| Differential Input | Yes |
| Maximum Single Supply Voltage | 5.25 V |
| Minimum Single Supply Voltage | 2.7 V |
| Typical Single Supply Voltage | 3.3|5 V |
| Typical Power Dissipation | 2.7 mW |
| Rad Hard | No |
| Polarity of Input Voltage | Unipolar|Bipolar |
| Supplier Package | SSOP |
| Input Signal Type | Single-Ended|Pseudo-Differential |
| Voltage Reference | External |
| Operating Temperature | 0 to 70 °C |
| Integral Nonlinearity Error | ±1 LSB |
| Package | 20SSOP |
| Replacement Part Number | PART-MAX147BCAP+T |
| Weight | Contact us |
| Country of Origin | - |
