Please contact us for more photos of MAX797CSE+T
| Part Number | MAX797CSE+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Quantity in stock | 624340 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 30V 16-Pin SOIC N T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MAX797CSE+T |
| Datasheet download |  MAX797CSE+T.pdf |
| Part Number | MAX797CSE+T |
|---|---|
| Switching Frequency | 330|175 kHz |
| Switching Regulator | Yes |
| Maximum Input Voltage | 30 V |
| Load Regulation | 2.5 % |
| Product Dimensions | 10 x 4 x 1.5 mm |
| Lead Finish | Matte Tin |
| Screening Level | Commercial |
| Output Voltage | 2.5 to 6|3.3|5 V |
| Type | Step Down |
| Rad Hard | No |
| Maximum Output Current | 10 A |
| Output Type | Adjustable|Fixed |
| Line Regulation | 0.06 %/V |
| Number of Outputs | 1 |
| Max Processing Temp | 260|300 |
| Minimum Input Voltage | 4.5 V |
| Operating Supply Voltage | 4.5 to 30 V |
| Mounting | Surface Mount |
| Efficiency | 96 % |
| MSL Level | 1 |
| Pin Count | 16 |
| Supplier Package | SOIC N |
| Operating Temperature | 0 to 70 °C |
| Package | 16SOIC N |
| Replacement Part Number | PART-MAX797CSE+T |
| Weight | Contact us |
| Country of Origin | - |
