Please contact us for more photos of AT91SAM7S256D-MU
| Part Number | AT91SAM7S256D-MU |
|---|---|
| Manufacturer | Microchip |
| Quantity in stock | 445060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-bit AT91SAM ARM7TDMI RISC 256KB Flash 1.8V 3.3V 64-Pin QFN Tray |
| Category | Microcontrollers MCU IC |
| Family | ARM Based Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | AT91SAM7S256D-MU |
| Datasheet download |  AT91SAM7S256D-MU.pdf |
| Part Number | AT91SAM7S256D-MU |
|---|---|
| Maximum Operating Supply Voltage | 1.95|3.6 V |
| Program Memory Size | 256 KB |
| Interface Type | JTAG/I2C/SPI/TWI/USART/USB |
| Program Memory Type | Flash |
| Watchdog | 1 |
| Supplier Package | QFN |
| Screening Level | Industrial |
| Operating Supply Voltage | 1.8|3.3 V |
| Device Core | ARM7TDMI |
| RAM Size | 64 KB |
| Maximum Speed | 55 MHz |
| Maximum Expanded Memory Size | 256 MB |
| Instruction Set Architecture | RISC |
| Rad Hard | No |
| Mounting | Surface Mount |
| Product Dimensions | 9 x 9 x 0.85(Max) |
| Data Bus Width | 32 Bit |
| Max Processing Temp | 260 |
| Number of Timers | 5 |
| Operating Temperature | -40 to 85 °C |
| Pin Count | 64 |
| MSL Level | 3 |
| On-Chip ADC | 8-chx10-bit|8-chx8-bit |
| Minimum Operating Supply Voltage | 1.65|3 V |
| Number of Programmable I/Os | 32 |
| Package | 64QFN |
| Replacement Part Number | PART-AT91SAM7S256D-MU |
| Weight | Contact us |
| Country of Origin | - |
