Please contact us for more photos of 0513380774
| Part Number | 0513380774 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 572040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board RCP 70 POS 0.4mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0513380774 |
| Datasheet download |  0513380774.pdf |
| Part Number | 0513380774 |
|---|---|
| Termination Method | Solder |
| Mounting | Surface Mount |
| Pitch | 0.4 mm |
| Product Dimensions | 17.1 x 3.4 x 1.34 mm |
| Housing Color | Black |
| Gender | RCP |
| Body Orientation | Straight |
| Housing Material | Liquid Crystal Polymer |
| Operating Temperature | -25 to 85 °C |
| Contact Plating | Gold Over Nickel |
| Lead Finish | Gold |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Product Depth | 3.4 mm |
| Product Height | 1.34 mm |
| Product Length | 17.1 mm |
| Replacement Part Number | PART-0513380774 |
| Weight | Contact us |
| Country of Origin | - |
