Please contact us for more photos of AXG206144
| Part Number | AXG206144 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 623190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board HDR 6 POS 0.35mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXG206144 |
| Datasheet download |  AXG206144.pdf |
| Part Number | AXG206144 |
|---|---|
| Pitch | 0.35 mm |
| Product Dimensions | 2.85 x 1.12 x 0.46 |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Lead Finish | Gold Over Nickel |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 85 °C |
| Rad Hard | No |
| Housing Material | Liquid Crystal Polymer |
| Mounting | Surface Mount |
| Termination Method | Solder |
| Pin Count | 6 |
| Body Orientation | Straight |
| Gender | HDR |
| Product Depth | 1.12 mm |
| Product Height | 0.46 mm |
| Product Length | 2.85 mm |
| Replacement Part Number | PART-AXG206144 |
| Weight | Contact us |
| Country of Origin | - |
