Please contact us for more photos of 0537800870
| Part Number | 0537800870 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 736400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 8 POS 1.25mm Solder RA SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0537800870 |
| Datasheet download |  0537800870.pdf |
| Part Number | 0537800870 |
|---|---|
| Housing Color | Natural |
| Pitch | 1.25 mm |
| Termination Method | Solder |
| Lead Finish | Tin |
| Mounting | Surface Mount |
| Body Orientation | Right Angle |
| Gender | HDR |
| Product Dimensions | 15.15 x 5.5 x 1.85 mm |
| Contact Material | Phosphor Bronze |
| Operating Temperature | -40 to 85 °C |
| Contact Plating | Gold Over Nickel |
| Housing Material | Thermoplastic |
| Product Depth | 5.5 mm |
| Product Height | 1.85 mm |
| Product Length | 15.15 mm |
| Replacement Part Number | PART-0537800870 |
| Weight | Contact us |
| Country of Origin | - |
