Please contact us for more photos of 0559171610
| Part Number | 0559171610 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 573310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 16 POS 2mm Solder ST Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 0559171610 |
| Datasheet download |  0559171610.pdf |
| Part Number | 0559171610 |
|---|---|
| Contact Plating | Tin Over Nickel |
| Operating Temperature | -25 to 85 °C |
| Termination Method | Solder |
| Housing Color | White |
| Pitch | 2 mm |
| Product Dimensions | 19.4 x 11.5 x 9.75 mm |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Lead Finish | Tin |
| Contact Material | Brass |
| Gender | HDR |
| Housing Material | Polybutylene Terephthalate |
| Product Depth | 11.5 mm |
| Product Height | 9.75 mm |
| Product Length | 19.4 mm |
| Replacement Part Number | PART-0559171610 |
| Weight | Contact us |
| Country of Origin | - |
