0845250009 Molex

0845250009 Images

Please contact us for more photos of 0845250009

Part Number	0845250009
Manufacturer	Molex
Quantity in stock	661270 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Contact PIN Crimp ST Cable Mount Reel
Category	Connectors
Family	Connector Contacts
ROHS Compliant	Yes
MSL Level	0845250009
Datasheet download	0845250009.pdf

Request Quotation for 0845250009

0845250009 Specifications

Part Number	0845250009
Contact Material	Copper Alloy
Contact Size	16
Product Dimensions	20.29 x 3.66 x 2.85 mm
Wire Size	16 to 18 AWG
Contact Plating	Tin Over Nickel
Gender	PIN
Rad Hard	No
Termination Method	Crimp
Mounting	Cable Mount
Body Orientation	Straight
Shielded	No
Product Depth	3.66 mm
Product Height	2.85 mm
Product Length	20.29 mm
Replacement Part Number	PART-0845250009
Weight	Contact us
Country of Origin	-
