Please contact us for more photos of 172316-1106
| Part Number | 172316-1106 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 550500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 6 POS 3.5mm Solder RA Thru-Hole Tray Ultra-Fit |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 172316-1106 |
| Datasheet download |  172316-1106.pdf |
| Part Number | 172316-1106 |
|---|---|
| Body Orientation | Right Angle |
| Rad Hard | No |
| Lead Finish | Tin Over Nickel |
| Termination Method | Solder |
| Operating Temperature | -40 to 120 °C |
| Pin Count | 6 |
| Gender | HDR |
| Housing Color | Black |
| Contact Material | Copper Alloy |
| Housing Material | Liquid Crystal Polymer |
| Pitch | 3.5 mm |
| Mounting | Through Hole |
| Contact Plating | Tin Over Nickel |
| Number of Rows | 2 |
| Max Processing Temp | 260 |
| Type | Shrouded Header |
| Product Depth | 18.67 mm |
| Product Length | 11.5 mm |
| Replacement Part Number | PART-172316-1106 |
| Weight | Contact us |
| Country of Origin | - |
