Please contact us for more photos of 5013310307
| Part Number | 5013310307 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 684350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 3 POS 1mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5013310307 |
| Datasheet download |  5013310307.pdf |
| Part Number | 5013310307 |
|---|---|
| Pitch | 1 mm |
| Contact Plating | Tin Over Nickel |
| Housing Material | Nylon 6/6 |
| Operating Temperature | -40 to 85 °C |
| Contact Material | Phosphor Bronze |
| Rad Hard | No |
| Housing Color | Natural |
| Termination Method | Solder |
| Product Dimensions | 5.24 x 3.5 x 5.41 mm |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Gender | HDR |
| Lead Finish | Tin |
| Product Depth | 3.5 mm |
| Product Height | 5.41 mm |
| Product Length | 5.24 mm |
| Replacement Part Number | PART-5013310307 |
| Weight | Contact us |
| Country of Origin | - |
