Please contact us for more photos of FDB14N30TM
| Part Number | FDB14N30TM |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 513620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 300V 14A 3-Pin(2+Tab) D2PAK T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | FDB14N30TM |
| Datasheet download |  FDB14N30TM.pdf |
| Part Number | FDB14N30TM |
|---|---|
| Maximum Gate Source Voltage | ±30 V |
| Supplier Package | D2PAK |
| Maximum Continuous Drain Current | 14 A |
| Maximum Drain Source Voltage | 300 V |
| Channel Type | N |
| Operating Temperature | -55 to 150 °C |
| Typical Turn-Off Delay Time | 30 ns |
| Channel Mode | Enhancement |
| Pin Count | 3 |
| Product Dimensions | 10.67 x 9.65 x 4.83 mm |
| Typical Fall Time | 75 ns |
| Rad Hard | No |
| Typical Rise Time | 105 ns |
| Lead Finish | Matte Tin |
| Max Processing Temp | 245 |
| Mounting | Surface Mount |
| Typical Turn-On Delay Time | 20 ns |
| MSL Level | 1 |
| RDS-on | 290@10V mOhm |
| Package | 3D2PAK |
| Replacement Part Number | PART-FDB14N30TM |
| Weight | Contact us |
| Country of Origin | - |
