Please contact us for more photos of IRFBC40STRLPBF
| Part Number | IRFBC40STRLPBF |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 333890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 600V 6.2A 3-Pin(2+Tab) D2PAK T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRFBC40STRLPBF |
| Datasheet download |  IRFBC40STRLPBF.pdf |
| Part Number | IRFBC40STRLPBF |
|---|---|
| Channel Mode | Enhancement |
| Max Processing Temp | 260|300 |
| Lead Finish | Matte Tin |
| Product Dimensions | 10.67 x 9.65 x 4.83 mm |
| Mounting | Surface Mount |
| Typical Fall Time | 20 ns |
| Typical Rise Time | 18 ns |
| Channel Type | N |
| Maximum Continuous Drain Current | 6.2 A |
| Maximum Gate Source Voltage | ±20 V |
| MSL Level | 1 |
| Pin Count | 3 |
| Typical Turn-Off Delay Time | 55 ns |
| Maximum Drain Source Voltage | 600 V |
| RDS-on | 1200@10V mOhm |
| Typical Turn-On Delay Time | 13 ns |
| Rad Hard | No |
| Supplier Package | D2PAK |
| Operating Temperature | -55 to 150 °C |
| Package | 3D2PAK |
| Replacement Part Number | PART-IRFBC40STRLPBF |
| Weight | Contact us |
| Country of Origin | - |
