Please contact us for more photos of NTK3134NT1G
| Part Number | NTK3134NT1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 465040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 20V 0.89A 3-Pin SOT-723 T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | NTK3134NT1G |
| Datasheet download |  NTK3134NT1G.pdf |
| Part Number | NTK3134NT1G |
|---|---|
| Channel Mode | Enhancement |
| Product Dimensions | 1.2 x 0.8 x 0.5 mm |
| Lead Finish | Matte Tin |
| Typical Rise Time | 4.8 ns |
| Mounting | Surface Mount |
| Pin Count | 3 |
| Typical Turn-Off Delay Time | 17.3 ns |
| Channel Type | N |
| Supplier Package | SOT-723 |
| MSL Level | 1 |
| Maximum Drain Source Voltage | 20 V |
| Maximum Continuous Drain Current | 0.89 A |
| RDS-on | [email protected] mOhm |
| Maximum Gate Source Voltage | ±6 V |
| Typical Fall Time | 7.4 ns |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Typical Turn-On Delay Time | 6.7 ns |
| Operating Temperature | -55 to 150 °C |
| Package | 3SOT-723 |
| Replacement Part Number | PART-NTK3134NT1G |
| Weight | Contact us |
| Country of Origin | - |
