STW13NK100Z STMicroelectronics

Please contact us for more photos of STW13NK100Z

Part Number	STW13NK100Z
Manufacturer	STMicroelectronics
Quantity in stock	243390 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans MOSFET N-CH 1KV 13A 3-Pin(3+Tab) TO-247 Tube
Category	Discrete Semiconductor
Family	Transistor
ROHS Compliant	Yes
MSL Level	STW13NK100Z
Datasheet download	STW13NK100Z.pdf

Request Quotation for STW13NK100Z

STW13NK100Z Specifications

Part Number	STW13NK100Z
Channel Mode	Enhancement
Maximum Gate Source Voltage	±30 V
RDS-on	700@10V mOhm
Typical Turn-Off Delay Time	145 ns
Typical Rise Time	35 ns
Channel Type	N
Mounting	Through Hole
Supplier Package	TO-247
Product Dimensions	15.75 x 5.15 x 20.15 mm
Pin Count	3
Maximum Drain Source Voltage	1000 V
Lead Finish	Tin
Maximum Continuous Drain Current	13 A
Typical Fall Time	45 ns
Rad Hard	No
Operating Temperature	-55 to 150 °C
Typical Turn-On Delay Time	45 ns
Package	3TO-247
Replacement Part Number	PART-STW13NK100Z
Weight	Contact us
Country of Origin	-
