Please contact us for more photos of NACE220M35V6.3X5.5TR13F
| Part Number | NACE220M35V6.3X5.5TR13F |
|---|---|
| Manufacturer | NIC Components |
| Quantity in stock | 409320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 35V 20% (6.3 X 5.5mm) SMD 9.05 Ohm 54mA 2000 hr 85\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | NACE220M35V6.3X5.5TR13F |
| Datasheet download |  NACE220M35V6.3X5.5TR13F.pdf |
| Part Number | NACE220M35V6.3X5.5TR13F |
|---|---|
| Equivalent Series Resistance | 9.05 Ohm |
| Lifetime | 2000 |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Tolerance | 20 % |
| Leakage Current | 7.7@2Min uA |
| Construction | Cylindrical |
| Ripple Current | 54 mA |
| Voltage(DC) | 35 V |
| Mounting | Surface Mount |
| Product Dimensions | 5.5 mm |
| MSL Level | 1 |
| Capacitance Value | 22 uF |
| Max Processing Temp | 250 |
| Package/Case | 6.3 X 5.5(Max) |
| Lead Finish | Tin/Bismuth |
| Product Diameter | 6.3 mm |
| Product Height | 5.5(Max) mm |
| Replacement Part Number | PART-NACE220M35V6.3X5.5TR13F |
| Weight | Contact us |
| Country of Origin | - |
