Please contact us for more photos of NSPE-H121M16V6.3X8NBYF
| Part Number | NSPE-H121M16V6.3X8NBYF |
|---|---|
| Manufacturer | NIC Components |
| Quantity in stock | 572270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 120uF 16V 20% (6.3 X 8mm) Cylindrical 1500mA 3000 hr 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | NSPE-H121M16V6.3X8NBYF |
| Datasheet download |  NSPE-H121M16V6.3X8NBYF.pdf |
| Part Number | NSPE-H121M16V6.3X8NBYF |
|---|---|
| Pin Count | 2 |
| Construction | Cylindrical |
| Lead Finish | Tin|Bismuth |
| Ripple Current | 1500 mA |
| Rad Hard | No |
| Tolerance | 20 % |
| Voltage(DC) | 16 V |
| Leakage Current | 19.2@2Min uA |
| Operating Temperature | -55 to 105 °C |
| Capacitance Value | 120 uF |
| Max Processing Temp | 260 |
| Package/Case | 6.3 X 8(Max) |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Product Dimensions | 6.3 X 8(Max) |
| Equivalent Series Resistance | 0.04 Ohm |
| Product Diameter | 6.3 mm |
| Product Height | 8(Max) mm |
| Replacement Part Number | PART-NSPE-H121M16V6.3X8NBYF |
| Weight | Contact us |
| Country of Origin | - |
