Please contact us for more photos of UPJ1C470MDD1TD
| Part Number | UPJ1C470MDD1TD |
|---|---|
| Manufacturer | Nichicon |
| Quantity in stock | 162540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 47uF 16V 20% (5 X 11mm) Radial Cylindrical 2mm 92mA 2000hr 105\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | UPJ1C470MDD1TD |
| Datasheet download |  UPJ1C470MDD1TD.pdf |
| Part Number | UPJ1C470MDD1TD |
|---|---|
| Package/Case | 5 X 11 |
| Leakage Current | 22.56@1Min uA |
| Voltage(DC) | 16 V |
| Construction | Cylindrical |
| Mounting | Through Hole |
| Capacitance Value | 47 uF |
| Lead Finish | Tin |
| Rad Hard | No |
| Ripple Current | 92 mA |
| Pin Count | 2 |
| Tolerance | 20 % |
| Lead Pitch For Radial | 2 mm |
| Max Processing Temp | 260 |
| Termination Style | Radial |
| Supplier Package | Radial |
| Operating Temperature | -55 to 105 °C |
| Product Diameter | 5 mm |
| Product Height | 11 mm |
| Replacement Part Number | PART-UPJ1C470MDD1TD |
| Weight | Contact us |
| Country of Origin | - |
