Please contact us for more photos of MC56F8036VLF
| Part Number | MC56F8036VLF |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 703260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 16-bit MC56F80xx CISC 64KB Flash 3.3V 48-Pin LQFP Brick |
| Category | Microcontrollers MCU IC |
| Family | 16 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MC56F8036VLF |
| Datasheet download |  MC56F8036VLF.pdf |
| Part Number | MC56F8036VLF |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| Program Memory Size | 64 KB |
| Max Processing Temp | 260 |
| MSL Level | 3 |
| Operating Supply Voltage | 3.3 V |
| Product Dimensions | 7 x 7 x 1.45 mm |
| Operating Temperature | -40 to 105 °C |
| Pin Count | 48 |
| Lead Finish | Matte Tin |
| Number of Programmable I/Os | 39 |
| Number of Timers | 4 |
| RAM Size | 8 KB |
| Supplier Package | LQFP |
| Minimum Operating Supply Voltage | 3 V |
| Instruction Set Architecture | CISC |
| Program Memory Type | Flash |
| Data Bus Width | 16 Bit |
| Interface Type | I2C/SCI/SPI |
| On-Chip ADC | 2(5-chx12-bit) |
| On-Chip DAC | 2-chx12-bit |
| Screening Level | Industrial |
| Maximum Speed | 32 MHz |
| Maximum Operating Supply Voltage | 3.6 V |
| Package | 48LQFP |
| Replacement Part Number | PART-MC56F8036VLF |
| Weight | Contact us |
| Country of Origin | - |
