Please contact us for more photos of EMI7204MUTAG
| Part Number | EMI7204MUTAG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 238370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | EMI Filter >23dB Flat Style SMD T R |
| Category | Filter |
| Family | EMI Filter |
| ROHS Compliant | Yes |
| MSL Level | EMI7204MUTAG |
| Datasheet download |  EMI7204MUTAG.pdf |
| Part Number | EMI7204MUTAG |
|---|---|
| Maximum Attenuation | >23 dB |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Product Dimensions | 1.7 x 1.35 x 0.55 mm |
| Type | 4 Channel EMI Filter and Integrated ESD Protection |
| MSL Level | 1 |
| Termination | Flat Style |
| Product Depth | 1.35 mm |
| Product Height | 0.55 mm |
| Product Length | 1.7 mm |
| Replacement Part Number | PART-EMI7204MUTAG |
| Weight | Contact us |
| Country of Origin | - |
