Please contact us for more photos of LM258DG
| Part Number | LM258DG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 745700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Dual GP \u00b116V 32V 8-Pin SOIC N Rail |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | LM258DG |
| Datasheet download |  LM258DG.pdf |
| Part Number | LM258DG |
|---|---|
| Power Supply Type | Single|Dual |
| Maximum Dual Supply Voltage | ±16 V |
| Technology | Bipolar |
| Minimum CMRR | 70 dB |
| Mounting | Surface Mount |
| Type | General Purpose Amplifier |
| Minimum Single Supply Voltage | 3 V |
| Maximum Input Offset Voltage | 5@30V mV |
| Typical Dual Supply Voltage | ±3|±5|±9|±12|±15 V |
| Shut Down Support | No |
| Typical Single Supply Voltage | 5|9|12|15|18|24|28 V |
| MSL Level | 1 |
| Pin Count | 8 |
| Minimum Dual Supply Voltage | ±1.5 V |
| Number of Channels per Chip | 2 |
| Lead Finish | Matte Tin |
| Maximum Input Bias Current | 0.15@5V uA |
| Maximum Supply Current | 1.2@5V@-25C to 85C mA |
| Typical Voltage Gain | 100 dB |
| Supplier Package | SOIC N |
| Maximum Single Supply Voltage | 32 V |
| Rail to Rail | No |
| Maximum Operating Supply Voltage | ±16|32 V |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Minimum PSRR | 65 dB |
| Operating Temperature | -25 to 85 °C |
| Package | 8SOIC N |
| Replacement Part Number | PART-LM258DG |
| Weight | Contact us |
| Country of Origin | - |
