| Part Number | MC7808CD2TG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 885320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LDO Regulator Pos 8V 1A 3-Pin(2+Tab) D2PAK Rail |
| Category | Power Management IC |
| Family | Linear Regulator |
| ROHS Compliant | Yes |
| MSL Level | MC7808CD2TG |
| Datasheet download |  MC7808CD2TG.pdf |
| Part Number | MC7808CD2TG |
|---|---|
| Output Type | Fixed |
| Accuracy | ±4 % |
| Lead Finish | Matte Tin |
| Load Regulation | 35 mV |
| Line Regulation | 32 mV |
| Mounting | Surface Mount |
| Output Voltage | 8 V |
| Input Voltage Range | 35 V |
| Number of Outputs | 1 |
| Maximum Quiescent Current | 8 mA |
| Function | LDO |
| MSL Level | 1 |
| Pin Count | 3 |
| Product Dimensions | 10.24 x 9.35 x 4.57 mm |
| Typical Quiescent Current | 3.3 mA |
| Maximum Input Voltage | 35 V |
| Maximum Output Current | 1 A |
| Max Processing Temp | 260 |
| Supplier Package | D2PAK |
| Rad Hard | No |
| Operating Temperature | 0 to 125 °C |
| Junction to Case | 5 °C/W |
| Typical Dropout Voltage @ Current | 2@1A V |
| Polarity | Positive |
| Package | 3D2PAK |
| Replacement Part Number | PART-MC7808CD2TG |
| Weight | Contact us |
| Country of Origin | - |
