Please contact us for more photos of GW JDSMS1.CC-EUFQ-5U8X-L1N2
| Part Number | GW JDSMS1.CC-EUFQ-5U8X-L1N2 |
|---|---|
| Manufacturer | OSRAM Opto Semiconductors |
| Quantity in stock | 753640 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LED, SMD, GW JDSMS1.CC Series, Uni-Color White, 32.7-40.8 lm, 2700K, \u00f87\"T R 1k |
| Category | Lighting |
| Family | LEDs |
| ROHS Compliant | Yes |
| MSL Level | GW JDSMS1.CC-EUFQ-5U8X-L1N2 |
| Datasheet download |  GW JDSMS1.CC-EUFQ-5U8X-L1N2.pdf |
| Part Number | GW JDSMS1.CC-EUFQ-5U8X-L1N2 |
|---|---|
| Product Dimensions | 5.4(Max) x 3.1(Max) x 0.87(Max) |
| Max Processing Temp | 260 |
| Lens Dimensions | 4.8 x 2.72 mm |
| Operating Temperature | -40 to 85 °C |
| Lens Appearance | Colored Diffused |
| Maximum Forward Voltage per Color | 3.4 V |
| Supplier Package | SMD |
| Rad Hard | No |
| Category | Chip LED |
| Viewing Angle | 120 ° |
| Number of LEDs | 1 |
| Lead Finish | Tin |
| Color Temperature | 2700 K |
| MSL Level | 3 |
| Mounting | Surface Mount |
| Type | Chip LED |
| Screening Level | Industrial |
| Maximum Forward Current | 180 mA |
| Pin Count | 4 |
| Luminous Flux | 40.8(Max) lm |
| Mounting Orientation | Top Mount |
| Package | 4SMD |
| Replacement Part Number | PART-GW JDSMS1.CC-EUFQ-5U8X-L1N2 |
| Weight | Contact us |
| Country of Origin | - |
