LA G6SP-DBEB-24-1 OSRAM Opto Semiconductors

Please contact us for more photos of LA G6SP-DBEB-24-1

Part Number	LA G6SP-DBEB-24-1
Manufacturer	OSRAM Opto Semiconductors
Quantity in stock	384400 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Amber 30.3lm 625nm Chip LED 6-Pin SMD T R
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	LA G6SP-DBEB-24-1
Datasheet download	LA G6SP-DBEB-24-1.pdf

Request Quotation for LA G6SP-DBEB-24-1

LA G6SP-DBEB-24-1 Specifications

Part Number	LA G6SP-DBEB-24-1
Maximum Forward Voltage per Color	2.5 V
Max Processing Temp	260
Number of LEDs	1
Category	Chip LED
Lead Finish	Matte Tin
Operating Temperature	-40 to 110 °C
Rad Hard	No
MSL Level	2
Product Dimensions	3.5(Max) x 3.2(Max) x 1.95(Max)
Peak Wavelength	625 nm
Luminous Flux	30.3 lm
Maximum Forward Current	200 mA
Reverse Voltage	12 V
Supplier Package	SMD
Pin Count	6
Mounting	Surface Mount
Viewing Angle	120 °
Mounting Orientation	Top Mount
Lens Appearance	Colorless Non Diffused
Type	Chip LED
Screening Level	Extended Industrial
Package	6SMD
Replacement Part Number	PART-LA G6SP-DBEB-24-1
Weight	Contact us
Country of Origin	-
