LY E65F-DAEB-46-1-R33-Z OSRAM Opto Semiconductors

Please contact us for more photos of LY E65F-DAEB-46-1-R33-Z

Part Number	LY E65F-DAEB-46-1-R33-Z
Manufacturer	OSRAM Opto Semiconductors
Quantity in stock	685500 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Yellow 8.95lm 590nm Chip LED 4-Pin PLCC T R
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	LY E65F-DAEB-46-1-R33-Z
Datasheet download	LY E65F-DAEB-46-1-R33-Z.pdf

Request Quotation for LY E65F-DAEB-46-1-R33-Z

LY E65F-DAEB-46-1-R33-Z Specifications

Part Number	LY E65F-DAEB-46-1-R33-Z
Supplier Package	PLCC
MSL Level	2
Reverse Voltage	12 V
Rad Hard	No
Category	Chip LED
Product Dimensions	3.4(Max) x 3(Max) x 3.5(Max)
Maximum Forward Current	70 mA
Number of LEDs	1
Peak Wavelength	597 nm
Mounting	Surface Mount
Max Processing Temp	260
Maximum Forward Voltage per Color	2.65 V
Operating Temperature	-40 to 110 °C
Viewing Angle	60 °
Mounting Orientation	Top Mount
Lens Dimensions	2.6 x 1.4 mm
Maximum Power Dissipation	190 mW
Lens Appearance	Colorless Non Diffused
Pin Count	4
Type	Chip LED
Luminous Flux	8.95 lm
Package	4PLCC
Replacement Part Number	PART-LY E65F-DAEB-46-1-R33-Z
Weight	Contact us
Country of Origin	-
