Please contact us for more photos of ECA1AHG103
| Part Number | ECA1AHG103 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 840200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 10000uF 10V 20% (16 X 31.5mm) Radial Aluminum Cylindrical Can 7.5mm 1890mA 2000 hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | ECA1AHG103 |
| Datasheet download |  ECA1AHG103.pdf |
| Part Number | ECA1AHG103 |
|---|---|
| Capacitance Value | .01 uF |
| Construction | Aluminum Cylindrical Can |
| Voltage(DC) | 10 V |
| Max Processing Temp | 250 to 260 |
| Lead Pitch For Radial | 7.5 mm |
| Lead Finish | Tin |
| Mounting | Through Hole |
| Package/Case | 16 X 31.5 |
| Leakage Current | 1000@2Min uA |
| Termination Style | Radial |
| Rad Hard | No |
| Ripple Current | 1890 mA |
| Tolerance | 20 % |
| Product Dimensions | 31.5 mm |
| Operating Temperature | -55 to 105 °C |
| Product Diameter | 16 mm |
| Product Height | 31.5 mm |
| Replacement Part Number | PART-ECA1AHG103 |
| Weight | Contact us |
| Country of Origin | - |
| Image | Part Number and Brand | Brief Description and PDF Datasheet |
|---|---|---|
|
Panasonic | Cap Aluminum 470uF 6.3V 20% (6.3 X 11.2mm) Radial Aluminum Cylindrical Can 2.5mm 230mA 1000 hr 105\u00b0C Bulk Download PDF datasheet for ECA0JHG471.pdf |
|
Nippon ChemiCon | Cap Aluminum 100uF 50V \u00b120% (10 X 10mm) Cylindrical 0.5 Ohm 247mA 2000hr 125\u00b0C Cardboard T R Download PDF datasheet for EMVH500ADA101MJA0G.pdf |
|
Nippon ChemiCon | Cap Aluminum 470uF 35V \u00b120% (10 X 16mm) Radial Aluminum Cylindrical Can 5mm 645mA 2000hr 85\u00b0C T R Download PDF datasheet for ESMG350ETD471MJ16S.pdf |
|
Nichicon | Cap Aluminum 2700uF 35V 20% (16 X 40mm) Radial 7.5mm 2610mA 5000 hr 105\u00b0C Bulk Download PDF datasheet for UPJ1V272MHD.pdf |
|
Panasonic | Cap Aluminum 15uF 16V 20% (4 X 7mm) Radial 1.5mm 33mA 1000 hr 105\u00b0C Bulk Download PDF datasheet for EEAGA1C150.pdf |
|
Nichicon | Cap Aluminum 47uF 50V 20% (8 X 16mm) Axial 160mA 2000 hr 85\u00b0C Download PDF datasheet for TVX1H470MAD.pdf |
|
Panasonic | Cap Aluminum 2000uF 35V 20% (18 X 25mm) Radial 7.5mm 0.02 Ohm 2470mA 2000 hr 135\u00b0C Bulk Download PDF datasheet for EEUTP1V202S.pdf |
|
Panasonic | Cap Aluminum 220uF 10V 20% (6.3 X 5.8mm) SMD 0.26 Ohm 300mA 2000 hr 105\u00b0C T R Download PDF datasheet for EEEFT1A221AP.pdf |
|
Nippon ChemiCon | Cap Aluminum 22uF 25V \u00b120% (6.3 X 5.2mm) Cylindrical 44mA 1000hr 105\u00b0C Cardboard T R Download PDF datasheet for EMVE250ADA220MF55G.pdf |
|
Nippon ChemiCon | Cap Aluminum 1000uF 16V \u00b120% (10 X 20mm) Radial Aluminum Cylindrical Can 5mm 0.046 Ohm 1400mA 7000hr 105\u00b0C Bulk Download PDF datasheet for EKY-160ELL102MJ20S.pdf |
