Please contact us for more photos of ECQE2105KB
| Part Number | ECQE2105KB |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 625100 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 1uF 250V PET 10% (15.3 X 7 X 14mm) Radial 12.5mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECQE2105KB |
| Datasheet download |  ECQE2105KB.pdf |
| Part Number | ECQE2105KB |
|---|---|
| Dielectric | PET |
| Dielectric Material | PET |
| Operating Temperature | -40 to 105 °C |
| Mounting | Through Hole |
| Package/Case | 15.3(Max) X 7(Max) X 14(Max) |
| Product Dimensions | 15.3 x 7 x 14 mm |
| Termination Style | Radial |
| Seated Plane Height | 15 mm |
| Rad Hard | No |
| Capacitance Value | 1 uF |
| Lead Finish | Tin |
| Max Processing Temp | 250 to 260 |
| Tolerance | 10 % |
| Lead Pitch For Radial | 12.5 mm |
| Voltage(DC) | 250 V |
| Product Depth | 7(Max) mm |
| Product Height | 14(Max) mm |
| Product Length | 15.3(Max) mm |
| Replacement Part Number | PART-ECQE2105KB |
| Weight | Contact us |
| Country of Origin | - |
