Please contact us for more photos of ECQE2105KF
| Part Number | ECQE2105KF |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 287970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 1uF 250V PET 10% (18.5 X 7.4 X 15mm) Radial 15mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECQE2105KF |
| Datasheet download |  ECQE2105KF.pdf |
| Part Number | ECQE2105KF |
|---|---|
| Dielectric | PET |
| Lead Pitch For Radial | 15 mm |
| Dielectric Material | PET |
| Operating Temperature | -40 to 105 °C |
| Seated Plane Height | 16 mm |
| Mounting | Through Hole |
| Termination Style | Radial |
| Type | Radial |
| Rad Hard | No |
| Capacitance Value | 1 uF |
| Package/Case | 18.5(Max) X 7.4(Max) X 15(Max) |
| Lead Finish | Tin |
| Voltage(DC) | 250 V |
| Tolerance | 10 % |
| Product Dimensions | 18.5 x 7.4 x 15 mm |
| Max Processing Temp | 250 to 260 |
| Product Depth | 7.4(Max) mm |
| Product Height | 15(Max) mm |
| Product Length | 18.5(Max) mm |
| Replacement Part Number | PART-ECQE2105KF |
| Weight | Contact us |
| Country of Origin | - |
