Please contact us for more photos of ECQV1H474JL
| Part Number | ECQV1H474JL |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 632100 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.47uF 50V PET 5% (7.3 X 6 X 7.3mm) Radial 5mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECQV1H474JL |
| Datasheet download |  ECQV1H474JL.pdf |
| Part Number | ECQV1H474JL |
|---|---|
| Operating Temperature | -40 to 105 °C |
| Dielectric | PET |
| Capacitance Value | 0.47 uF |
| Voltage(DC) | 50 V |
| Product Dimensions | 7.3 x 6 x 7.3 mm |
| Seated Plane Height | 8.3 mm |
| Termination Style | Radial |
| Mounting | Through Hole |
| Type | Radial |
| Lead Pitch For Radial | 5 mm |
| Lead Finish | Tin |
| Max Processing Temp | 250 to 260 |
| Tolerance | 5 % |
| Rad Hard | No |
| Package/Case | 7.3(Max) X 6(Max) X 7.3(Max) |
| Product Depth | 6(Max) mm |
| Product Height | 7.3(Max) mm |
| Product Length | 7.3(Max) mm |
| Replacement Part Number | PART-ECQV1H474JL |
| Weight | Contact us |
| Country of Origin | - |
