Please contact us for more photos of EEEFPV680XAP
| Part Number | EEEFPV680XAP |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 293020 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 68uF 35V 20% (6.3 X 7.7mm) SMD 0.16 Ohm 600mA 2000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEEFPV680XAP |
| Datasheet download |  EEEFPV680XAP.pdf |
| Part Number | EEEFPV680XAP |
|---|---|
| Capacitance Value | 68 uF |
| Mounting | Surface Mount |
| Voltage(DC) | 35 V |
| Lifetime | 2000 hr |
| Construction | Cylindrical |
| Equivalent Series Resistance | 0.16 Ohm |
| Package/Case | 6.3 X 7.7 |
| Leakage Current | 23.8@2Min uA |
| Rad Hard | No |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Ripple Current | 600 mA |
| Operating Temperature | -55 to 105 °C |
| Product Dimensions | 7.7 mm |
| Lead Finish | Tin/Bismuth |
| Product Diameter | 6.3 mm |
| Product Height | 7.7 mm |
| Replacement Part Number | PART-EEEFPV680XAP |
| Weight | Contact us |
| Country of Origin | - |
