Please contact us for more photos of EEFSL0J560R
| Part Number | EEFSL0J560R |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 258470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 56uF 6.3V 20% (7.3 X 4.3 X 1.8mm) SMD 0.009 Ohm 3000mA 1000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEFSL0J560R |
| Datasheet download |  EEFSL0J560R.pdf |
| Part Number | EEFSL0J560R |
|---|---|
| Voltage(DC) | 6.3 V |
| Product Dimensions | 7.3 x 4.3 x 1.8 mm |
| Rad Hard | No |
| Tolerance | 20 % |
| Construction | Flat |
| Ripple Current | 3000 mA |
| Package/Case | 7.3 X 4.3 X 1.8 |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Operating Temperature | -40 to 105 °C |
| Capacitance Value | 56 uF |
| Equivalent Series Resistance | 0.009 Ohm |
| Max Processing Temp | 240 |
| Product Depth | 4.3 mm |
| Product Height | 1.8 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-EEFSL0J560R |
| Weight | Contact us |
| Country of Origin | - |
