Please contact us for more photos of ELL4GG4R7N
| Part Number | ELL4GG4R7N |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 121300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Choke Coil Shielded 4.7uH 30% 100KHz 1A 1515 Embossed Carrier T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ELL4GG4R7N |
| Datasheet download |  ELL4GG4R7N.pdf |
| Part Number | ELL4GG4R7N |
|---|---|
| Package/Case | 1515 |
| Tolerance | 30 % |
| Protection Style | Shielded |
| Product Dimensions | 4 x 4 x 1.4 mm |
| Lead Finish | Tin |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Test Frequency | 100 kHz |
| Product Depth | 4 mm |
| Product Height | 1.4 mm |
| Product Length | 4 mm |
| Replacement Part Number | PART-ELL4GG4R7N |
| Weight | Contact us |
| Country of Origin | - |
