Please contact us for more photos of ERJU02F7683X
| Part Number | ERJU02F7683X |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 848150 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0402 768K Ohm 1% 1 10W \u00b1200ppm \u00b0C Molded SMD Punched Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | ERJU02F7683X |
| Datasheet download |  ERJU02F7683X.pdf |
| Part Number | ERJU02F7683X |
|---|---|
| Termination Style | Wraparound |
| Case Style | Molded |
| Supplier Package | 0402 |
| Pin Count | 2 |
| Rad Hard | No |
| Temperature Coefficient | ±200 ppm/°C |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| Case Size | 0402 |
| Power Rating | 0.1 W |
| Resistance Value | 768 kOhm |
| Lead Finish | Tin |
| Operating Temperature | -55 to 155 °C |
| Tolerance | 1 % |
| Product Dimensions | 1 x 0.5 x 0.35 |
| Product Depth | 0.5 mm |
| Product Height | 0.35 mm |
| Product Length | 1 mm |
| Product Weight | 0.8 mg |
| Replacement Part Number | PART-ERJU02F7683X |
| Weight | Contact us |
| Country of Origin | - |
