Please contact us for more photos of BAP55LX,315
| Part Number | BAP55LX,315 |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 182250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode PIN Attenuator Switch 50V 2-Pin SOD T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAP55LX,315 |
| Datasheet download |  BAP55LX,315.pdf |
| Part Number | BAP55LX,315 |
|---|---|
| Frequency Range | UHF|SHF |
| Typical Carrier Life Time | 0.27 us |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Configuration | Single |
| Type | Attenuator|Switch |
| Pin Count | 2 |
| Maximum Diode Capacitance | 0.28@20V pF |
| Maximum Series Resistance @ Maximum IF | 0.8@100mA Ohm |
| Maximum Series Resistance @ Minimum IF | [email protected] Ohm |
| Maximum Forward Voltage | 1.1@50mA V |
| Mounting | Surface Mount |
| Maximum Forward Current | 100 mA |
| Lead Finish | Tin |
| Supplier Package | SOD |
| Maximum Power Dissipation | 135 mW |
| Maximum Reverse Voltage | 50 V |
| Product Dimensions | 1.05 x 0.65 x 0.36 mm |
| Package | 2SOD |
| Replacement Part Number | PART-BAP55LX,315 |
| Weight | Contact us |
| Country of Origin | - |
