Please contact us for more photos of PI6C557-03ALE
| Part Number | PI6C557-03ALE |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 607910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | PLL Clock Generator Single 16-Pin TSSOP Tube |
| Category | RF & Microwave |
| Family | RF ICs |
| ROHS Compliant | Yes |
| MSL Level | PI6C557-03ALE |
| Datasheet download |  PI6C557-03ALE.pdf |
| Part Number | PI6C557-03ALE |
|---|---|
| Number of Elements per Chip | 1 |
| Operating Supply Voltage | 3.3 V |
| Operating Temperature | -40 to 85 °C |
| Pin Count | 16 |
| Output Frequency Range | 25 to 200 MHz |
| Supplier Package | TSSOP |
| Rad Hard | No |
| Mounting | Surface Mount |
| Type | PLL Clock Generator |
| Minimum Input Frequency | 25 MHz |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Screening Level | Industrial |
| Package | 16TSSOP |
| Replacement Part Number | PART-PI6C557-03ALE |
| Weight | Contact us |
| Country of Origin | - |
