Please contact us for more photos of PA2744NLT
| Part Number | PA2744NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 393630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Line Toroid 280uH -35% to 30% 4A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PA2744NLT |
| Datasheet download |  PA2744NLT.pdf |
| Part Number | PA2744NLT |
|---|---|
| Inductance | 280 uH |
| Maximum DC Resistance | 13.2 mOhm |
| Type | Power Line |
| Maximum DC Current | 4 A |
| Tolerance | -35 to 30 % |
| Max Processing Temp | 245 |
| Product Dimensions | 13(Max) x 13(Max) x 5.6(Max) |
| Rad Hard | No |
| Operating Temperature | -40 to 130 °C |
| Technology | Toroid |
| Package/Case | 13(Max) X 13(Max) X 5.6(Max) |
| Pin Count | 4 |
| Product Depth | 13(Max) mm |
| Product Height | 5.6(Max) mm |
| Product Length | 13(Max) mm |
| Replacement Part Number | PART-PA2744NLT |
| Weight | Contact us |
| Country of Origin | - |
