Please contact us for more photos of PA2891.321HLT
| Part Number | PA2891.321HLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 883270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Bead Wirewound 320nH 10% 100KHz 45A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PA2891.321HLT |
| Datasheet download |  PA2891.321HLT.pdf |
| Part Number | PA2891.321HLT |
|---|---|
| Operating Temperature | -40 to 130 °C |
| Package Dimensions | 13.7 x 12.95 x 8.08 mm |
| Inductance | 320 nH |
| Pin Count | 2 |
| Maximum DC Current | 45 A |
| Maximum DC Resistance | 242 uOhm |
| Rad Hard | No |
| Type | Power Bead |
| Test Frequency | 100 kHz |
| Technology | Wirewound |
| Supplier Package | SMD |
| Package/Case | 13.7(Max) X 12.95(Max) X 8.08(Max) |
| Tolerance | 10 % |
| Product Depth | 12.95(Max) mm |
| Product Height | 8.08(Max) mm |
| Product Length | 13.7(Max) mm |
| Replacement Part Number | PART-PA2891.321HLT |
| Weight | Contact us |
| Country of Origin | - |
