Please contact us for more photos of PA4390.121HLT
| Part Number | PA4390.121HLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 172470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Bead Shielded 120nH 15% 100KHz 68A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | PA4390.121HLT |
| Datasheet download |  PA4390.121HLT.pdf |
| Part Number | PA4390.121HLT |
|---|---|
| Tolerance | 15 % |
| Pin Count | 2 |
| Package/Case | 10(Max) X 7(Max) X 10(Max) |
| Protection Style | Shielded |
| Rad Hard | No |
| Maximum DC Resistance | 185 mOhm |
| Type | Power Bead |
| Product Dimensions | 10(Max) x 7(Max) x 10(Max) |
| Supplier Package | SMD |
| Test Frequency | 100 kHz |
| Operating Temperature | -40 to 130 °C |
| Product Depth | 7(Max) mm |
| Product Height | 10(Max) mm |
| Product Length | 10(Max) mm |
| Replacement Part Number | PART-PA4390.121HLT |
| Weight | Contact us |
| Country of Origin | - |
