Please contact us for more photos of 1N4004RLG
| Part Number | 1N4004RLG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 327870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 400V 1A 2-Pin DO-41 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | 1N4004RLG |
| Datasheet download |  1N4004RLG.pdf |
| Part Number | 1N4004RLG |
|---|---|
| Mounting | Through Hole |
| Rad Hard | No |
| Pin Count | 2 |
| Type | Switching Diode |
| Product Dimensions | 5.2 x 2.7 x 2.7 mm |
| Peak Reverse Current | 10 uA |
| Peak Forward Voltage | 1.1 V |
| Supplier Package | DO-41 |
| Operating Temperature | -65 to 175 °C |
| Peak Non-Repetitive Surge Current | 30 A |
| Peak Average Forward Current | 1@Ta=75C A |
| Peak Reverse Repetitive Voltage | 400 V |
| Configuration | Single |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Package | 2DO-41 |
| Replacement Part Number | PART-1N4004RLG |
| Weight | Contact us |
| Country of Origin | - |
