Please contact us for more photos of 1N4007-E3 54
| Part Number | 1N4007-E3 54 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 188980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode 1KV 1A 2-Pin DO-204AL T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | 1N4007-E3 54 |
| Datasheet download |  1N4007-E3 54.pdf |
| Part Number | 1N4007-E3 54 |
|---|---|
| Peak Reverse Current | 5 uA |
| Peak Non-Repetitive Surge Current | 45 A |
| Lead Finish | Matte Tin |
| Peak Forward Voltage | 1.1 V |
| Supplier Package | DO-204AL |
| Peak Reverse Repetitive Voltage | 1000 V |
| Mounting | Through Hole |
| Operating Temperature | -50 to 150 °C |
| Product Dimensions | 5.2 x 2.7 x 2.7 mm |
| Configuration | Single |
| Rad Hard | No |
| Pin Count | 2 |
| Peak Average Forward Current | 1@Ta=75C A |
| Max Processing Temp | 275 |
| Package | 2DO-204AL |
| Replacement Part Number | PART-1N4007-E3 54 |
| Weight | Contact us |
| Country of Origin | - |
