Please contact us for more photos of 1N4531,113
| Part Number | 1N4531,113 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 530530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 75V 0.2A 2-Pin DO-34 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | 1N4531,113 |
| Datasheet download |  1N4531,113.pdf |
| Part Number | 1N4531,113 |
|---|---|
| Peak Non-Repetitive Surge Current | 4 A |
| Operating Temperature | -65 to 200 °C |
| Peak Forward Voltage | [email protected] V |
| Supplier Package | DO-34 |
| Pin Count | 2 |
| Mounting | Through Hole |
| Configuration | Single |
| Peak Average Forward Current | 0.2 A |
| Max Processing Temp | 260 |
| Peak Reverse Recovery Time | 4 ns |
| Rad Hard | No |
| Lead Finish | Tin |
| Product Dimensions | 3.04 x 1.6 x 1.6 mm |
| Peak Reverse Repetitive Voltage | 75 V |
| Type | Switching Diode |
| Peak Reverse Current | 0.025 uA |
| MSL Level | 1 |
| Package | 2DO-34 |
| Replacement Part Number | PART-1N4531,113 |
| Weight | Contact us |
| Country of Origin | - |
