Please contact us for more photos of BAS116LP3-7
| Part Number | BAS116LP3-7 |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 555060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 85V 2-Pin DFN T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAS116LP3-7 |
| Datasheet download |  BAS116LP3-7.pdf |
| Part Number | BAS116LP3-7 |
|---|---|
| Peak Forward Voltage | [email protected] V |
| Operating Temperature | -65 to 150 °C |
| Peak Reverse Repetitive Voltage | 85 V |
| Peak Reverse Current | 0.01@75V uA |
| Max Processing Temp | 260 |
| Peak Reverse Recovery Time | 3000 ns |
| Product Dimensions | 0.62 x 0.32 x 0.28 mm |
| Configuration | Single |
| Pin Count | 2 |
| Peak Non-Repetitive Surge Current | 4 A |
| Lead Finish | Matte Tin |
| Supplier Package | DFN |
| Rad Hard | No |
| Type | Switching Diode |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Package | 2DFN |
| Replacement Part Number | PART-BAS116LP3-7 |
| Weight | Contact us |
| Country of Origin | - |
