Please contact us for more photos of BAS21,235
| Part Number | BAS21,235 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 751420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 250V 0.2A 3-Pin TO-236AB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAS21,235 |
| Datasheet download |  BAS21,235.pdf |
| Part Number | BAS21,235 |
|---|---|
| Rad Hard | No |
| Pin Count | 3 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Type | Switching Diode |
| Lead Finish | Tin |
| Product Dimensions | 3 x 1.4 x 1 mm |
| Peak Forward Voltage | 1.25 V |
| Peak Reverse Current | 0.1@200V uA |
| Operating Temperature | -65 to 150 °C |
| Supplier Package | TO-236AB |
| Peak Reverse Repetitive Voltage | 250 V |
| Peak Non-Repetitive Surge Current | 1.7 A |
| Max Processing Temp | 260 |
| Peak Reverse Recovery Time | 50 ns |
| Peak Average Forward Current | 0.2 A |
| Configuration | Single |
| Package | 3TO-236AB |
| Replacement Part Number | PART-BAS21,235 |
| Weight | Contact us |
| Country of Origin | - |
