Please contact us for more photos of BAS40H,115
| Part Number | BAS40H,115 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 859680 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 40V 0.12A 2-Pin SOD-123F T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAS40H,115 |
| Datasheet download |  BAS40H,115.pdf |
| Part Number | BAS40H,115 |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| Peak Forward Voltage | [email protected] V |
| Lead Finish | Tin |
| MSL Level | 1 |
| Supplier Package | SOD-123F |
| Operating Temperature | -65 to 150 °C |
| Peak Non-Repetitive Surge Current | 0.2 A |
| Peak Reverse Repetitive Voltage | 40 V |
| Peak Average Forward Current | 0.12 A |
| Max Processing Temp | 260 |
| Product Dimensions | 2.7 x 1.7 x 1.2 mm |
| Peak Reverse Current | 10 uA |
| Configuration | Single |
| Type | Schottky Diode |
| Pin Count | 2 |
| Package | 2SOD-123F |
| Replacement Part Number | PART-BAS40H,115 |
| Weight | Contact us |
| Country of Origin | - |
