Please contact us for more photos of BAV199E6327
| Part Number | BAV199E6327 |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 249770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 85V 0.2A 3-Pin SOT23 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAV199E6327 |
| Datasheet download |  BAV199E6327.pdf |
| Part Number | BAV199E6327 |
|---|---|
| Rad Hard | No |
| Peak Non-Repetitive Surge Current | 4.5 A |
| Product Dimensions | 2.9 x 1.3 x 1 mm |
| Pin Count | 3 |
| Peak Forward Voltage | [email protected] V |
| Peak Average Forward Current | 0.2 A |
| Max Processing Temp | 260 |
| Operating Temperature | -65 to 150 °C |
| Supplier Package | SOT-23 |
| Configuration | Dual Series |
| Type | Switching Diode |
| Peak Reverse Recovery Time | 1500 ns |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Peak Reverse Repetitive Voltage | 85 V |
| Peak Reverse Current | 0.005@75V uA |
| Package | 3SOT-23 |
| Replacement Part Number | PART-BAV199E6327 |
| Weight | Contact us |
| Country of Origin | - |
