Please contact us for more photos of BAV70W,115
| Part Number | BAV70W,115 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 390450 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 100V 0.175A 3-Pin SC-70 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAV70W,115 |
| Datasheet download |  BAV70W,115.pdf |
| Part Number | BAV70W,115 |
|---|---|
| Product Dimensions | 2.2 x 1.35 x 1 mm |
| Max Processing Temp | 260 |
| Peak Average Forward Current | 0.175 A |
| Peak Forward Voltage | [email protected] V |
| Lead Finish | Tin |
| Pin Count | 3 |
| Supplier Package | SC-70 |
| Configuration | Dual Common Cathode |
| Type | Switching Diode |
| Operating Temperature | -65 to 150 °C |
| Peak Reverse Repetitive Voltage | 100 V |
| Peak Reverse Recovery Time | 4 ns |
| Peak Non-Repetitive Surge Current | 4 A |
| MSL Level | 1 |
| Peak Reverse Current | 0.5@80V uA |
| Mounting | Surface Mount |
| Rad Hard | No |
| Package | 3SC-70 |
| Replacement Part Number | PART-BAV70W,115 |
| Weight | Contact us |
| Country of Origin | - |
